The theory of machines subject is fundamental for mechanical engineering, This blog post provides TOM 313313 IMP Questions & Notes for Class Test.
All MSBTE diploma colleges are conducting class tests in the upcoming weeks, To help students we provided all required study material for the theory of machines.
TOM 313313 IMP Questions for Class Test
Unit – I Fundamentals and Types of Mechanism
- 2 marks questions
- Define a) Higher pair and b )Lower pair with one example
- Define: a) Kinematic link (b) Kinematic chain(c) Kinematic pair with example
- State the types of constrained motion. Sketch any one.
- Define the following with an example (i)Mechanism (ii) Machine (iii) Inversion
- Define sliding pair and turning pair with an example
- List any four inversions of a single slider crank chain mechanism
- 4 Marks Questions
- Explain the crank and slotted lever mechanism with a neat sketch
- State the inversions of the bar chain mechanism and explain to anyone with a neat sketch
- Give the classification of kinematic pairs. Explain any one
- Explain with a neat sketch working of the beam engine
- Explain with a neat sketch working of Scotch Yoke mechanism
- Full PDF:
TOM 313313 Theory of Machines Notes for Class Test
- Unit – I Fundamentals and Types of Mechanism
- Unit – II Velocity and Acceleration in Mechanism
- Unit – III Cam and Follower
